Drive Motors
The system utilizes two DC motor. One motor is used to drive the glass panels and the
other is used for the headliner (visor) and wind deflector.
The hall sensors are integrated in the motors to detect motor revolutions. These signals
are forwarded to the MDS for analysis.
Floating Headliner
The floating headliner consists of two parts controlled by a Bowden Cable.
The headliner is interlocked to the function of the glass roofs. The headliner must be
opened before the glass sunroof will open. On closing the glass sunroof must be closed
before the headliner can be closed or
Double selecting open or close on the switch will allow the glass panels and the headlin-
er to move at the same time.
44
E61 Sports Wagon
Drive Motors
