Luggage Compartment Roller Cover
The partition net is integrated in the standard luggage compartment roller cover (similar to
E39/2). The luggage compartment roller cover is attached at the D-pillars. It can be
removed and, with the rear seat backrest folded down, attached to this backrest.
Depending on where the roller cover is fastened, the partition net can be attached at the
support elements in the headliner (behind B-pillar or C-pillar).
53
E61 Sports Wagon
Index Explanation
1
Luggage compartment roller cover, bottom position
2
Luggage compartment roller cover, top position
3
Net partition fastening point at C-pillars
4
Net partition fastening point at B-pillars
Fastening points for luggage compartment roller cover/net partition
