ATTENTION

Incorrect battery disconnec-

tion

Danger of short circuit

Follow the disconnection

sequence.

Disconnect battery earth lead 1

first.

Then disconnect the positive

battery cable 2.

Press locking mechanism 3

and loosen connector 4.

Press locking mechanism 1

and remove relay 2.

Remove the screw 5.

Remove battery carrier 6 to the

front.

Lift out battery 7 upwards; if it

is difficult to move, moving it

back and forth will help.

Install battery

NOTICE

If the motorcycle was

disconnected from the battery

for a longer time, the current

date must be entered in the

instrument cluster to ensure the

proper operation of the service

display.

127

Maintenance

Other manuals for BMW F 800 R

Questions and Answers:

Need help?

Do you have a question about the BMW F 800 R and is the answer not in the manual?

General

Engine Type	Liquid-cooled, 4-stroke parallel twin
Displacement	798 cc
Power	90 hp (66 kW) @ 8, 000 rpm
Transmission	6-speed
ABS	Standard
Fuel System	Electronic fuel injection
Torque	86 Nm (63 lb-ft) @ 5, 800 rpm
Front Suspension	43 mm telescopic fork
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
Fuel Capacity	16 l
Dry Weight	177 kg
Rear Suspension	Double-sided swing arm, central spring strut, spring preload adjustable
