Apply uniform pressure to push
front wheel stand down and
raise motorcycle.
with center stand
OE
ATTENTION
Lifting-off of the center stand
if the vehicle is raised too
high
Component damage cause by
tipping over
When raising the motorcy-
cle, make sure that the center
stand remains on the ground.
Adjust the height of the front
wheel stand if necessary.
Ensure that motorcycle is
standing securely.
Bulb mask
Fold bulb mask downward
Remove screws 1.
Swing bulb mask 2 upward
while making sure that bush-
ings 3 are installed.
Mounting bulb mask
Swing bulb mask 2 upward
while making sure that bush-
ings 3 are installed.
Install screws 1.
Engine oil
Check engine oil level
ATTENTION
Misinterpretation of the oil
filling quantity, as the oil
level is temperature-depen-
dent (the higher the tempera-
ture, the higher the oil level)
9
96
z
Maintenance
