Make sure that the battery

earth lead 1 has sufficient dis-

tance (arrow) to the relay car-

rier 2.

Installing center fairing panel

( 122).

Install seat ( 54).

Set clock ( 48).

Fuses

Replacing main fuse

ATTENTION

Bypassing defective fuses

Risk of short circuit and fire

Do not bypass defective fuses.

Replace defective fuses with

new fuses.

Turn off ignition.

Park motorcycle, ensuring that

support surface is firm and

level.

Removing center fairing panel

( 121).

Replace defective fuse 1.

NOTICE

If the fuses blow frequently, have

the electrical system checked by

an authorized specialized work-

shop, preferably an authorized

BMW Motorrad retailer.

Main fuse

30 A (Voltage regulator)

Installing center fairing panel

( 122).

129

Maintenance
