BMW F 800 R User Manual

Electronic immobilizer is
active
General warning light shows
yellow.
+ "EWS" is indicated.
Possible cause:
The key being used is not autho-
rized for starting, or communica-
tion between the key and engine
electronics is disrupted.
Remove other motorcycle keys
from the ignition key ring.
Use the reserve key.
Have the defective key re-
placed, preferably by an autho-
rized BMW Motorrad retailer.
Fuel down to reserve
Fuel-reserve warning light
lights up.
WARNING
Rough engine running or
switching off of the engine
due to a fuel shortage
Accident hazard, damage to cat-
alytic converter
Do not drive to the extent that
the fuel tank is completely
empty.
Possible cause:
At the most, the fuel tank still
contains the reserve fuel quantity.
Fuel reserve
Approx. 3.2 quarts (Approx.
3 l)
Refueling procedure ( 84).
Coolant temperature too
high
General warning light shows
red.
The temperature symbol
flashes.
ATTENTION
Riding with overheated en-
gine
Engine damage
Be sure to observe the mea-
sures listed below.
Possible cause:
Coolant level is too low.
Checking coolant level
( 104).
If coolant level is too low:
Topping up coolant ( 104).
3
29
z Displays

BMW F 800 R Specifications

General

Engine Type	Liquid-cooled, 4-stroke parallel twin
Displacement	798 cc
Power	90 hp (66 kW) @ 8, 000 rpm
Transmission	6-speed
ABS	Standard
Fuel System	Electronic fuel injection
Torque	86 Nm (63 lb-ft) @ 5, 800 rpm
Front Suspension	43 mm telescopic fork
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
Fuel Capacity	16 l
Dry Weight	177 kg
Rear Suspension	Double-sided swing arm, central spring strut, spring preload adjustable
