BMW F 800 R User Manual

Replace battery
ATTENTION
Unsuitable or improperly in-
serted batteries
Component damage
Use specified battery (see
"Technical Data" chapter).
When inserting the battery,
make sure that the polarity is
correct.
Remove screw 1 and take off
lower housing section 2.
Slide old battery 3 forward un-
der bow 4.
Install new battery. Ensure that
positive terminal of battery is at
top.
Fit lower housing section to
lug 5 on front edge and close
it. When doing so, pay atten-
tion to the guide pins 6.
Install screw.
The LED of the remote control
lights up; i.e. the remote con-
trol must be activated.
To activate the remote control
within the range of the receiver,
press the button 1 twice.
LED 2 begins to flash and
goes out after a few seconds.
The remote-control is again
ready to be used.
5
65
z Alarm system

BMW F 800 R Specifications

General

Engine Type	Liquid-cooled, 4-stroke parallel twin
Displacement	798 cc
Power	90 hp (66 kW) @ 8, 000 rpm
Transmission	6-speed
ABS	Standard
Fuel System	Electronic fuel injection
Torque	86 Nm (63 lb-ft) @ 5, 800 rpm
Front Suspension	43 mm telescopic fork
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
Fuel Capacity	16 l
Dry Weight	177 kg
Rear Suspension	Double-sided swing arm, central spring strut, spring preload adjustable
