BMW G 650 Xmoto Rider's Manual

Troubleshooting chart
Engine does not start at all or is difficult to start.
Possible cause Remedy
Kill switch activated. Kill switch in operating position (run).
Side stand extended and gear engaged. Retract the side stand ( 44).
Gear engaged and clutch not disengaged. Select neutral or pull clutch lever ( 44).
No fuel in tank. Refuelling ( 48)
Battery not adequately charged. Charge the battery when connected ( 89)
9
100
z Technical data
ProCarManuals.com

BMW G 650 Xmoto Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Max Power	53 hp (39 kW) @ 7, 000 rpm
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Transmission	5-speed
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Engine Type	Single cylinder, four-stroke
Max Torque	60 Nm (44 lb-ft) @ 5, 250 rpm
Front Suspension	45 mm
Front Brake	Single disc, 2-piston caliper
Rear Brake	Single disc, 240 mm, 1-piston caliper
Fuel Capacity	9.5 l
