BMW G 650 Xmoto Rider's Manual

wise and hold it in this posi-
tion.
Lift seat 2 at the rear and
release the key.
Remove the seat.
Place the seat, upholstered
side down, on a clean sur-
face.
Installing seat
Push seat 2 forward into
mount 3.
Firmly press down on the
seat at the rear.
The seat engages with an
audible click.
Check that the seat is se-
cure.
Mirrors
Adjusting mirrors
Turn the mirror to the cor-
rect position.
Adjusting mirror arm
Slacken nut 1.
4
34
z Operation
ProCarManuals.com

BMW G 650 Xmoto Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Max Power	53 hp (39 kW) @ 7, 000 rpm
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Transmission	5-speed
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Engine Type	Single cylinder, four-stroke
Max Torque	60 Nm (44 lb-ft) @ 5, 250 rpm
Front Suspension	45 mm
Front Brake	Single disc, 2-piston caliper
Rear Brake	Single disc, 240 mm, 1-piston caliper
Fuel Capacity	9.5 l
