BMW G 650 Xmoto Rider's Manual

Note that there is a
danger of coming into
contact with the hot exhaust
silencer when you turn the
knob.
Allow the silencer to cool.
Adjust spring preload by
turning knob 1.
If you want to increase
spring preload, turn the
knob toward HARD.
If you want to reduce spring
preload, turn the knob to-
ward SOFT.
Spring preload, basic
setting
Turn the knob as far as it
will go in the "SOFT" dir-
ection, then turn it 10 full
turns in the "HARD" direc-
tion. (Full load of fuel, with
rider 85 kg)
Damping
Telescopic-
fork damping
You can fine—tune the sus-
pension to the road surface
by adjusting both the com-
pression—stage and rebound—
stage damping characteristics
of the telescopic forks.
The rebound—stage setting
controls the way the sus-
pension reacts as it extends,
whereas the compression—
stage setting influences com-
pression of the front forks un-
der load.
The harder the setting, the
more the movement that the
forks can make to absorb sur-
face irregularities is damped.
When you choose a soft set-
ting the forks respond all the
more rapidly to surface irregu-
larities.
Adjusting compression
stage for the telescopic
forks
Make sure the ground is
level and firm and place the
motorcycle on its stand.
4
37
z Operation
ProCarManuals.com

BMW G 650 Xmoto Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Max Power	53 hp (39 kW) @ 7, 000 rpm
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Transmission	5-speed
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Engine Type	Single cylinder, four-stroke
Max Torque	60 Nm (44 lb-ft) @ 5, 250 rpm
Front Suspension	45 mm
Front Brake	Single disc, 2-piston caliper
Rear Brake	Single disc, 240 mm, 1-piston caliper
Fuel Capacity	9.5 l
