BMW G 650 Xmoto Rider's Manual

Turning screws clockwise:
reduces chain tension.
Turning screws counter—
clockwise: increases chain
tension.
Check chain tension ( 70)
Make sure that scale read-
ings 4 are the same on left
and right.
Tighten locknuts 2 on left
and right by turning them
clockwise.
Locknut of the final-
drive chain tensioning
screw
25 Nm
Tighten quick—release axle
nut 1 to the specified tight-
ening torque.
Nut on quick-release
axle, rear
80 Nm
Checking chain wear
Make sure the ground is
level and firm and place the
motorcycle on its stand.
Pull the chain back at
the rearmost point of the
sprocket.
The tips of the sprocket
teeth must remain inside
the chain links.
If the chain can be pulled
back far enough to expose
the tips of the sprocket teeth:
Consult a specialist work-
shop, preferably an author-
ised BMW Motorrad dealer.
Wheels
Recommended tyres
For each size of tyre BMW
Motorrad tests and classifies
as roadworthy certain makes.
BMW Motorrad cannot as-
sess the suitability or provide
any guarantee of road safety
for other tyres.
BMW Motorrad recommends
using only tyres tested by
BMW Motorrad.
You can obtain detailed in-
formation from your author-
ised BMW Motorrad dealer or
on the Internet at www.bmw—
motorrad.com.
7
71
z Maintenance
ProCarManuals.com

BMW G 650 Xmoto Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Max Power	53 hp (39 kW) @ 7, 000 rpm
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Transmission	5-speed
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Engine Type	Single cylinder, four-stroke
Max Torque	60 Nm (44 lb-ft) @ 5, 250 rpm
Front Suspension	45 mm
Front Brake	Single disc, 2-piston caliper
Rear Brake	Single disc, 240 mm, 1-piston caliper
Fuel Capacity	9.5 l
