BMW G 650 Xmoto Rider's Manual

pull it to the rear to disen-
gage it from holder 4.
Remove the side panel.
Installing right side panel
Begin by seating the side
panel in holder 4, then seat
it in holder 3.
Install screws 2.
Install screw 1 at the front
right.
Install the seat ( 34)
Number-plate carrier
Removing number-
plate carrier
Make sure the ground is
level and firm and place the
motorcycle on its stand.
Remove four screws 1.
7
92
z Maintenance
ProCarManuals.com

BMW G 650 Xmoto Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Max Power	53 hp (39 kW) @ 7, 000 rpm
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Transmission	5-speed
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Engine Type	Single cylinder, four-stroke
Max Torque	60 Nm (44 lb-ft) @ 5, 250 rpm
Front Suspension	45 mm
Front Brake	Single disc, 2-piston caliper
Rear Brake	Single disc, 240 mm, 1-piston caliper
Fuel Capacity	9.5 l
