BMW K 1300 R User Manual

Turn the end silencer to its
initial position.
Insert screw 4 into the rear
footrest and tighten to the spe-
cified tightening torque.
Silencer to rear footrest
22 Nm
Arrange the end silencer
so that the handle of the
reversible-blade screwdriver
(toolkit) can fit between the
wheel and the end silencer.
Position the clamp as shown.
Tighten screw 3 of the ball-
joint clamp to the specified
tightening torque.
Silencer with ball-joint
clamp on manifold
35 Nm
Hold the silencer cover 2
in position and fit the three
bolts 1.
without centre stand
OA
Remove the rear-wheel stand
8
116
z Maintenance

BMW K 1300 R Specifications

General

Displacement	1, 293 cc
Max Torque	140 Nm at 8, 250 rpm
Transmission	6-speed
Fuel Capacity	19 liters
Seat Height	820 mm
Dry Weight	217 kg
Front Suspension	BMW Motorrad Duolever
Bore x Stroke	80 mm x 64.3 mm
Compression Ratio	13.0:1
Fuel System	Electronic fuel injection
Alternator	580 W
Battery	12 V / 14 Ah, maintenance-free
Drive	Shaft drive
Front Wheel Travel	115 mm
Rear Wheel Travel	135 mm
Wheelbase	1, 585 mm
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Weight, Unladen, Ready for Road, Fully Fueled	243 kg
Permitted Total Weight	450 kg
Max. Payload	207 kg
Top Speed	Over 200 km/h
Max Power	173 hp at 9, 250 rpm
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
Fuel Type	Unleaded super
Clutch	Multiple-disc clutch in oil bath
Frame	Bridge-type frame, cast aluminium
ABS	BMW Motorrad ABS
Rims	Cast aluminum
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder engine, four valves per cylinder, two overhead camshafts
