BMW K 1300 R User Manual

The motorcycle can topple
and fall on its side.
Make sure that the motorcycle
cannot topple sideways.
Push the motorcycle onto the
transportation flat and hold it in
position: do not place it on the
side stand or centre stand.
Risk of damaging compon-
ents.
Take care not to trap
components such as brake lines
or wires.
At the front, place the strap
over the frame and route it
downwards.
Feed the strap forwards
through the wheel carrier and
tighten it downwards.
At the rear, secure the straps
to the rear footrests on both
sides and tighten the straps.
Tighten all the straps uniformly;
the motorcycle's suspension
should be compressed as
tightly as possible front and
rear.
5
81
z Riding

BMW K 1300 R Specifications

General

Displacement	1, 293 cc
Max Torque	140 Nm at 8, 250 rpm
Transmission	6-speed
Fuel Capacity	19 liters
Seat Height	820 mm
Dry Weight	217 kg
Front Suspension	BMW Motorrad Duolever
Bore x Stroke	80 mm x 64.3 mm
Compression Ratio	13.0:1
Fuel System	Electronic fuel injection
Alternator	580 W
Battery	12 V / 14 Ah, maintenance-free
Drive	Shaft drive
Front Wheel Travel	115 mm
Rear Wheel Travel	135 mm
Wheelbase	1, 585 mm
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Weight, Unladen, Ready for Road, Fully Fueled	243 kg
Permitted Total Weight	450 kg
Max. Payload	207 kg
Top Speed	Over 200 km/h
Max Power	173 hp at 9, 250 rpm
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
Fuel Type	Unleaded super
Clutch	Multiple-disc clutch in oil bath
Frame	Bridge-type frame, cast aluminium
ABS	BMW Motorrad ABS
Rims	Cast aluminum
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder engine, four valves per cylinder, two overhead camshafts
