Always have the security of the

fasteners checked by a specialist

workshop, preferably an author-

ised BMW Motorrad dealer.

Install spacing bushing 4 in the

wheel hub.

The front wheel must be

installed right way round to

rotate in the correct direction.

Note the direction-of-rotation ar-

rows on the tyre or the wheel

rim.

Roll the front wheel into posi-

tion between the front forks.

Raise the front wheel, insert

quick-release axle 3 and tight-

en to specified torque.

Quick-release axle in axle

holder

50 Nm

Tighten axle clamping screw 2

to the specified torque.

Clamp screw of quick-

release axle

19 Nm

with BMW Motorrad Integral

ABS II

Insert the ABS sensor into its

bore and install screw 1.

Remove the front-wheel stand.

Ease the brake calipers on to

the brake discs.

121

Maintenance
