Rear wheel

Type of rear suspension BMW EVO Paralever; cast light-alloy single

swinging arm with two joints and torque reaction

link

Type of rear suspension Central spring strut with single-tube, gas-filled

shock absorber, steplessly adjustable rebound-

stage damping, progressive compression-stage

damping and hydraulically adjustable spring pre-

load

with Electronic Suspension Adjustment (ESA)

Central spring strut with single-tube gas-filled

shock absorber, electrically adjustable rebound

damping and electro-hydraulically adjustable

spring preload

Spring travel at rear wheel 220 mm

152

Technical data

Other manuals for BMW R 1200 GS ADVENTURE

Questions and Answers:

Need help?

Do you have a question about the BMW R 1200 GS ADVENTURE and is the answer not in the manual?

General

Displacement	1, 170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Length	2, 255 mm
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Wet Weight	260 kg
Fuel Capacity	30 liters
Tires Front	120/70 R19
Tires Rear	170/60 R17
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
ABS	BMW Motorrad Integral ABS
Seat Height	890 mm
