in order to prevent overloading of
the on-board electrics.
Cable routing
The cables from the power sock-
ets to the auxiliary devices must
be routed in such a way that
they:
Do not impede the rider
Do not restrict the steering
angle or obstruct handling
Cannot be trapped
Case
with cases
OA
Heat shield, left case
The left case is exposed to a
considerable amount of heat on
account of the position of the
rear silencer.
Severe damage to the left
case caused by heat from
the rear silencer.
Use only a case correctly fitted
with a heat shield.
Before you ride off, make sure
that heat shield 1 is in position
on the left case.
The geometry of the case carri-
ers enables you to use the cases
from the predecessor model. Un-
der these circumstances your au-
thorised BMW motorcycle dealer
will supply a retrofit heat shield.
Opening cases
Turn the key to the OPEN pos-
ition in the case lock.
Push lock barrel 1 down.
Lever 2 pops up.
7
77
z
