Pull the release lever all the
way up.
The lid of the topcase opens.
Close the topcase
Pull release lever 2 all the way
up.
Close the lid of the topcase
and hold it down. Check that
nothing is trapped between the
lid and the case.
Push release lever 2 down until
it engages.
Turn the key in the topcase
lock to the LOCK position and
remove the key from the lock.
Removing topcase
Turn the key to the RELEASE
position in the topcase lock.
The handle pops out.
Pull handle 3 up as far as it will
go.
Lift the topcase at the rear and
remove it from the luggage
carrier.
Installing topcase
Pull the topcase handle up as
far as it will go.
7
80
z
Accessories
