BMW R 1200GS User Manual

socket is switched off when this
happens.
Comply with the operating in-
structions of the charger.
NOTICE
If you are unable to charge the
battery through the on-board
socket, you may be using a char-
ger that is not compatible with
your motorcycle's electronics. If
this happens, charge the battery
directly at the terminals of the
battery that is disconnected from
the vehicle.
Charging battery when
disconnected
Charge the battery using a
suitable charger.
Comply with the operating in-
structions of the charger.
Once the battery is fully
charged, disconnect the
charger's terminal clips from
the battery terminals.
NOTICE
The battery has to be recharged
at regular intervals in the course
of a lengthy period of disuse.
See the instructions for caring
for your battery. Always fully re-
charge the battery before restor-
ing it to use.
Removing battery
Switch off the ignition.
Remove screw 1.
Each battery cover slightly for-
ward at the top at positions 2.
In order not to damage the bat-
tery cover or the mount, work
the battery cover up at posi-
tion 3 to remove.
with alarm system (DWA)
OE
If applicable, switch off the anti-
theft alarm.
Disconnect battery negative
lead 1 and disengage rubber
strap 2.
8
163
z Maintenance

BMW R 1200GS Specifications

General

Final Drive	Shaft drive
Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Fuel Capacity	Approx. 20 l
Seat Height	850 / 870 mm
Front Brake	Dual 305 mm discs, 4-piston calipers
ABS	Standard
Wheelbase	1, 507 mm
Transmission	Constant mesh 6-speed gearbox with helical gear teeth
Rear Suspension	Paralever, WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
