BMW R 1200GS User Manual

Engage pivot lever 1 at the top
limit position to set the case to
minimum volume.
Engage pivot lever 1 at the
bottom limit position to set the
case to maximum volume.
Close the case.
Closing cases
with cases
OA
Turn the lock with the key until
it is at right angles to the for-
ward direction of travel.
Close the case lid.
The lid engages with an aud-
ible click.
ATTENTION
Closure of carrying handle
with case lock latched
Damage to locking tab
Make sure that the case lock
is at right angles to the forward
direction of travel when you
close the carry handle.
Close carry handle 1.
Turn key 2 counter-clockwise
and remove.
Removing cases
with cases
OA
Turn key 1 clockwise.
Keep the yellow latch 2 held
and fold out the carry handle 3.
9
172
z Accessories

BMW R 1200GS Specifications

General

Final Drive	Shaft drive
Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Fuel Capacity	Approx. 20 l
Seat Height	850 / 870 mm
Front Brake	Dual 305 mm discs, 4-piston calipers
ABS	Standard
Wheelbase	1, 507 mm
Transmission	Constant mesh 6-speed gearbox with helical gear teeth
Rear Suspension	Paralever, WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
