Push yellow button 1 forward

and at the same time open the

lid of the topcase.

Adjusting topcase volume

with topcase

Open the topcase and remove

all its contents.

Engage pivot lever 1 at the

front limit position to set the

case to maximum volume.

Engage pivot lever 1 at the

rear limit position to set the

case to minimum volume.

Close the topcase.

Closing topcase

with topcase

Press down firmly on the top-

case lid to close.

ATTENTION

Closure of carrying handle

with case lock latched

Damage to locking tab

Make sure that the topcase

lock is vertical when you close

the carry handle.

Close carry handle 1.

The handle engages with an

audible click.

Turn key 2 counter-clockwise

and remove.

175

Accessories
