BMW R 1200GS User Manual

in order to be able to switch the
RPA off.
Switching on ignition ( 50).
Repeatedly press button 1
briefly until the top display
line 2 shows SETUP ENTER.
Press and hold button 1 to
start the SETUP menu.
Press button 1 briefly to go to
the next menu item RDC.
In the top display line 2, RDC
is displayed.
The bottom display line 3
shows the preset value.
Press button 4 briefly in order
to change the set value.
The following settings are pos-
sible RDC Enduro:
ON: The RDC warning symbol in
the display does not show. Only
a tyre pressure that is outside the
permitted tolerance is displayed.
OFF: The RDC warning
symbol is shown in the
display and the tyre pressure
outside of the permitted toler-
ance is shown.
Installing encoding plug
Switching off ignition ( 51).
Removing front seat ( 89).
ATTENTION
Dirt and damp penetrating
inside open connectors
Malfunctions
4
80
z Operation

BMW R 1200GS Specifications

General

Final Drive	Shaft drive
Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Fuel Capacity	Approx. 20 l
Seat Height	850 / 870 mm
Front Brake	Dual 305 mm discs, 4-piston calipers
ABS	Standard
Wheelbase	1, 507 mm
Transmission	Constant mesh 6-speed gearbox with helical gear teeth
Rear Suspension	Paralever, WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
