compensated with the air pres-
sure tester at the filling station.
Example
According to the Rider's Man-
ual, the tire pressure should
be as follows:
36.3 psi (2.5 bar)
The multifunction display
shows the following figure:
33.4 psi (2.3 bar)
The shortfall is thus:
2.9 psi (0.2 bar)
The tester at the filling station
shows:
34.8 psi (2.4 bar)
To obtain the correct tire pres-
sure, that has to be increased
to the following figure:
37.7 psi (2.6 bar)
ESA
with dynamic ESA
OE
Adjustment options
Using the Dynamic ESA elec-
tronic suspension adjustment
system you can easily adjust your
motorcycle to the load being car-
ried.
Using leveling sensors, Dynamic
ESA detects movements of the
running gear and responds to
them by adjusting the damper
valves. As a result, the running
gear is adjusted to the conditions
of the ground.
In addition, the damping char-
acteristic can be made harder
(HARD) or softer (SOFT) relative
to the normal setting (NORMAL).
with Pro driving modes
OE
The suspension setting depends
on the riding mode selected.
Damping set by the riding mode
can be changed by the rider.
6
104
z Technology in detail

BMW R 1200RT Specifications

General

Displacement	1170 cc
ABS	Standard
Engine Type	Air/liquid-cooled, four-stroke, flat-twin
Power	125 hp (92 kW) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Fuel Capacity	25 liters
Seat Height	805 mm (adjustable to 825 mm)
Weight	274 kg (with full fuel tank)
Front Suspension	Telelever
Rear Suspension	BMW Paralever
Front Brake	Dual disc, 320 mm
Rear Brake	Single disc, 276 mm
Wheelbase	1, 485 mm
