BMW R 1200RT User Manual

Top up engine oil
Make sure ground is level and
firm and park motorcycle.
Clean area adjacent to oil fill
location.
Remove oil filler plug 2 using
oil filler tool 1.
Locate the oil filler tool 1 on
the engine oil filler plug 2 and
turn counterclockwise to re-
move.
Check engine oil level ( 107).
Both too little and too
much engine oil can lead to
engine damage.
Always make sure that the oil
level is correct.
Add engine oil up to specified
level.
Engine oil, quantity for
topping up
max 1 quarts (max 0.95 l) (Dif-
ference between MIN and
MAX)
Check engine oil level ( 107).
Install sealing plug 2 of engine
oil fill location.
Brake system
Checking brake operation
Actuate the handbrake lever.
Pressure point must be clearly
perceptible.
Actuate the footbrake lever.
Pressure point must be clearly
perceptible.
If no clear pressure points are
perceptible:
Incorrect working practices
endanger the reliability of
the brakes.
Have all work on the brake sys-
tem carried out by specialists.
Have the brakes checked at an
authorized workshop, preferably
an authorized BMW Motorrad
retailer.
Check front brake pad
thickness
Make sure ground is level and
firm and park motorcycle.
7
108
z Maintenance

BMW R 1200RT Specifications

General

Displacement	1170 cc
ABS	Standard
Engine Type	Air/liquid-cooled, four-stroke, flat-twin
Power	125 hp (92 kW) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Fuel Capacity	25 liters
Seat Height	805 mm (adjustable to 825 mm)
Weight	274 kg (with full fuel tank)
Front Suspension	Telelever
Rear Suspension	BMW Paralever
Front Brake	Dual disc, 320 mm
Rear Brake	Single disc, 276 mm
Wheelbase	1, 485 mm
