can obtain the tools set from
your authorised BMW Motorrad
dealer.
Engine oil
Check engine oil level
The oil level varies with
the temperature of the
oil. The higher the temperature,
the higher the level of oil in the
sump. Checking the oil level with
the engine cold or after no more
than a short ride will lead to mis-
interpretation of oil level.
In order to ensure that the en-
gine oil level is read correctly,
check the oil level only after at
engine operating temperature.
Switch off the engine when it is
at operating temperature.
Make sure the ground is level
and firm and place the motor-
cycle on its centre stand.
Wait five minutes for the oil to
drain into the oil pan.
Check the oil level in oil-level
indicator 1.
Engine oil, specified level
Between MIN and MAX marks
If the oil level is below the MIN
mark:
Top up the engine oil ( 112).
If the oil level is above the MAX
mark:
Have the oil level corrected
by a specialist workshop,
preferably an authorised
BMW Motorrad dealer.
7
111
z Maintenance

BMW R1200GS Specifications

General

Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Transmission	6-speed
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Suspension	BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Wheelbase	1, 507 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Torque	125 Nm (92 lb-ft) @ 6, 500 rpm
Frame	Two-section frame, front- and bolted on rear frame
Traction Control	Automatic Stability Control (ASC)
Seat Height	850 / 870 mm (adjustable)
Fuel Capacity	20 l
Rear Suspension	BMW Motorrad Paralever; cast aluminum single-sided swing arm with WAD strut (weight-related damping)
