BMW R1200GS User Manual

Troubleshooting chart
Engine does not start or is difficult to start.
Possible cause Rectification
Side stand extended and gear engaged Retract the side stand.
Gear engaged and clutch not disengaged Select neutral or pull the clutch lever.
No fuel in tank Refuelling ( 94).
Battery flat Charge battery when connected ( 135).
10
160
z Technical data

BMW R1200GS Specifications

General

Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Transmission	6-speed
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Suspension	BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Wheelbase	1, 507 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Torque	125 Nm (92 lb-ft) @ 6, 500 rpm
Frame	Two-section frame, front- and bolted on rear frame
Traction Control	Automatic Stability Control (ASC)
Seat Height	850 / 870 mm (adjustable)
Fuel Capacity	20 l
Rear Suspension	BMW Motorrad Paralever; cast aluminum single-sided swing arm with WAD strut (weight-related damping)
