BMW R1200GS User Manual

Engine
Location of engine number Crankcase, bottom right, below starter motor
Engine design Air-/liquid-cooled two-cylinder four-stroke
opposed-twin engine with two overhead spur-
gear-driven camshafts and one balancing shaft
Displacement 1170 cm
3
Cylinder bore 101 mm
Piston stroke 73 mm
Compression ratio 12.5:1
Nominal output 92 kW, at engine speed: 7750 min
-1
with power reduction
OE
79 kW, at engine speed: 7750 min
-1
Torque 125 Nm, at engine speed: 6500 min
-1
with power reduction
OE
122 Nm, at engine speed: 5250 min
-1
Maximum engine speed max 9000 min
-1
Idle speed 1150 min
-1
, engine at regular operating tempera-
ture
10
163
z Technical data

BMW R1200GS Specifications

General

Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Transmission	6-speed
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Suspension	BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Wheelbase	1, 507 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Torque	125 Nm (92 lb-ft) @ 6, 500 rpm
Frame	Two-section frame, front- and bolted on rear frame
Traction Control	Automatic Stability Control (ASC)
Seat Height	850 / 870 mm (adjustable)
Fuel Capacity	20 l
Rear Suspension	BMW Motorrad Paralever; cast aluminum single-sided swing arm with WAD strut (weight-related damping)
