Place box from the top into the

mountings 1 and 2.

Press latching flap 1 down until

resistance is felt.

Then simultaneously press

down latching flap and red re-

lease lever 2.

The latching flap engages.

Closing the carry handle

while the case lock is in

line with the forward direction of

travel can result in damage to the

locking tongue.

Make sure that the case lock is

at right angles to the forward dir-

ection of travel when you close

the carry handle.

Close carry handle 1.

Turn key 2 counter-clockwise

and remove.

Topcase

with topcase

Opening topcase

Turn key 1 clockwise.

Keep the yellow latch 2 held

and fold out the carry handle 3.

150

Accessories

Other manuals for BMW R1200GS

Questions and Answers:

Need help?

Do you have a question about the BMW R1200GS and is the answer not in the manual?

General

Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Transmission	6-speed
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Suspension	BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Wheelbase	1, 507 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Torque	125 Nm (92 lb-ft) @ 6, 500 rpm
Frame	Two-section frame, front- and bolted on rear frame
Traction Control	Automatic Stability Control (ASC)
Seat Height	850 / 870 mm (adjustable)
Fuel Capacity	20 l
Rear Suspension	BMW Motorrad Paralever; cast aluminum single-sided swing arm with WAD strut (weight-related damping)
