BMW R1200GS User Manual

units can be changed to suit the
new wheel sizes.
RDC label
with tyre pressure monitoring
(RDC)
OE
Incorrect tyre fitting can
damage the RDC sensors.
Be sure to explain to the au-
thorised BMW Motorrad dealer
or the specialist workshop that
the wheel is fitted with an RDC
sensor.
If the motorcycle is equipped
with RDC, each wheel rim bears
an adhesive label indicating the
position of the RDC sensor.
When changing the tyre, take
care not to damage the RDC
sensor. Be sure to draw the
attention of the authorised
BMW Motorrad dealer or
specialist workshop to the fact
that the wheel is fitted with an
RDC sensor.
Removing front wheel
Make sure the ground is level
and firm and place the motor-
cycle on its centre stand.
Disengage the cable for the
wheel-speed sensor from re-
taining clips 1 and 2.
Remove screw 3 and remove
the wheel-speed sensor from
its bore.
Mask off the parts of the wheel
rim that could be scratched in
the process of removing the
brake calipers.
Once the calipers have
been removed, there is
a risk of the brake pads being
pressed together to the extent
that they cannot be slipped back
7
120
z Maintenance

BMW R1200GS Specifications

General

Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Transmission	6-speed
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Suspension	BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Wheelbase	1, 507 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Torque	125 Nm (92 lb-ft) @ 6, 500 rpm
Frame	Two-section frame, front- and bolted on rear frame
Traction Control	Automatic Stability Control (ASC)
Seat Height	850 / 870 mm (adjustable)
Fuel Capacity	20 l
Rear Suspension	BMW Motorrad Paralever; cast aluminum single-sided swing arm with WAD strut (weight-related damping)
