Program structure | ACS 611 | 43
en
4. Program structure
4.1 Calibration and tare
Input Menu
1.
+ <3>
2. Enter
1111.
3. Confirm with E.
TANK CALIBRATION
IN OIL CALIBRATION
OUT OIL CALIBRATION
PRES. CALIBRATION
TANK TARE
IN OIL TARE
OUT OIL TARE
4.2 Settings
Input Menu
1.
+ <3>
2. Enter 2222.
3. Confirm with E.
LANGUAGE
DATE/TIME
UNIT OF MEASURE
HOSES LENGTH
CONTRAST
GARAGE ADDRESS
FLUSHING
OIL SCALE
UV DYE
DATABASE UPDATE
SERIAL NUMBER
EXPERT MODE
4.3 Repair
Input Menu
1.
+ <3>
2. Enter 5555.
3. Confirm with E.
CHANGE FILTER
CHANGE OIL
4.4 Vehicle and customer data
Input Menu 1 Menu 2
<Database>
STANDARD SPECS EUROPEAN DATABASE
TRUCK DATABASE
USER SPECS SELECT MODEL :
DELETE MODEL :
ADD MODEL :
VEHICLE DATAS
4.5 Menu
Input Menu 1 Menu 2
<Menu>
PERFORMANCE TESTS
DIAGNOSTIC
TANK FILLING
TANK RECYCLING
ZEROING OIL SCALES
REPORT MANAGEMENT PRINT REPORT
EXPORT DATA
DELETE DATA
4.6 Manual mode
Input Menu
<RECOVERY>
R Automatic emptying
R Extraction
R Oil drain
R Pressure test
SELECT PORTS
...
Input Menu
<VACUUM>
SET VACUUM TIME
...
Input Menu
<CHARGE>
SELECT PORTS
...
4.7 Automatic mode
Input Menu
<AUTOMATIC>
SELECT PORTS
...
4.8 Flush (optional)
Input Menu
<Flush>
SET VACUUM TIME
...
4.9 Enter
Input Menu
<Enter>
Information on current filling
capacities of fresh and used oil
bottles and the internal refrigerant
cylinder
