Notes on cycling with the eBike
system
When does the eBike drive work?
The eBike drive assists your cycling only when you are
pedaling. If you do not pedal, the assistance will not
work. The motor output always depends on the pedal-
ing force you apply.
If you apply less force, you will receive less assistance
than if you apply a lot of force. This applies irrespec-
tive of the assistance level.
The eBike drive automatically switches off at speeds
over 20mph. When the speed falls below 20mph,
the drive automatically becomes available again.
An exception applies to the push assistance function,
in which the eBike can be pushed at low speed with-
out pedaling. The pedals may rotate when the push
assistance is in use.
You can also use the eBike as a normal bicycle with-
out assistance at any time, either by switching off the
eBike system or by setting the assistance level to
OFF. The same applies when the battery is drained.
Interaction between the eBike system and
gear-shifting
The gear-shifting should be used with an eBike drive
in the same way as with a normal bicycle (observe the
operating instructions of your eBike on this point).
Irrespective of the type of gear-shifting, it is advisable
to briefly stop pedaling when changing gear. This will
facilitate the gear change and reduce wear on the
powertrain.
By selecting the correct gear, you can increase your
speed and range while applying the same amount of
force.
Test the range of your eBike in different conditions
before planning longer and more demanding trips.
u Read and understand the influences on the oper-
ating range when planning your ride (see "Influ-
ences on range", pageEnglish–8).
Influences on range
The range is affected by a number of factors, such as:
– Assistance level
– Speed
– Gear shifting behavior
– Tire type and tire pressure
– Age and condition of the battery
– Route profile (gradients) and conditions (road sur-
face)
– Headwind and ambient temperature
– Weight of eBike, rider and luggage
For this reason, it is not possible to predict the range
accurately before and during a trip. However, as a
general rule:
– With the same assistance level on the eBike drive:
The less energy you need to exert in order to reach
a certain speed (e.g. by changing gears optimally),
the less energy the eBike drive will consume and
the higher the range per battery charge will be.
– The higher the selected assistance level under oth-
erwise constant conditions, the smaller the range
will be.
Note: Plan your routes so that you can always reach
your destination without motor assistance.
Operating your Bosch Drive System
Getting Ready to Ride
u Read and understand all safety warnings and in-
structions. Failure to follow the below warnings
could result in death or serious injury.
u Protect others from death or serious injury. Pre-
vent unauthorized use. Always remove battery
from the bicycle when not in use and store in a se-
cure location. Failure to secure your bicycle from
unauthorized use can result in death or serious in-
jury to others.
u Read and understand the influences on the oper-
ating range when planning your ride (see "Influ-
ences on range", pageEnglish–8).
Before your first ride
Check your bicycle owner’s manual for important in-
formation about the bike components like brakes,
pedals, gears, shifting, etc.
u While riding, do not become distracted by the
onboard computer and always remain alert to all
riding conditions. The on-board computer should
only be used in a stationary and safe start-up posi-
tion. Utilize the operating unit to change motor as-
sistance levels while riding.
u Check your bicycle manual for maximum riding
weight of your bicycle. Overloading your bicycle
can result in component failure which can result in
death or serious injury. Typically maximum riding
weight is defined by the sum of the rider’s weight
plus the weight of any luggage.
Intended Use
u Understand your bike and its intended use by
consulting your bicycle owner’s manual. Using
your bike the wrong way and for a purpose it was
not designed can result in death or serious injury.
The Bosch Drive System components are intended
exclusively for your eBike and must not be used for
other purposes.
Your Bosch drive unit is not intended for towing an-
other bicycle. For trailer towing, consult your bicycle
owner’s manual and trailer owner’s manual for towing
instructions and towing compatibility.
Safe Start-up Procedure
u Follow the safe startup procedure below. Failure
to follow safe startup procedure can result in death
or serious injury.
Preparations
Before starting check the following:
– Check that you have unplugged the battery charger
– Your battery pack is locked in place (Pull on the bat-
tery pack to ensure it is locked in place)
– Remove the battery pack key
Start Riding
– Sit in the saddle with both feet touching the ground
and two hands on the handlebars.
– Once you are in a stable position, turn on the Bosch
on-board computer. The Bosch Drive System will al-
ways start up in OFF mode.
– Place both hands on the handlebars and begin ped-
aling.
