Bosch DIVAR IP 7000 User Manual

18 en | Rack installation DIVAR IP 7000 (2U)
2016.07 | V2 | DOC Installation Manual Bosch Sicherheitssysteme GmbH
4 Rack installation
4.1 Unpacking the system
You should inspect the box the chassis was shipped in and note if it was damaged in any way.
If the chassis itself shows damage, file a damage claim with the carrier who delivered it and
notify the respective Bosch RMA desk.
Due to the weight of the system: After opening the top of the shipping box, one person should
stand at either end and lift the disk array out together.
Be sure to read the safety precautions.
4.2 Preparing for setup
Read this section in its entirety before you begin the installation procedure outlined in the
sections that follow.
4.2.1 Choosing a setup location
– Place the system near at least one grounded power outlet.
– Place the system in a clean, dust-free area that is well ventilated. Avoid areas where heat,
electrical noise and electromagnetic fields are generated.
– Leave approximately 25inches clearance in front of the rack to be able to open the front
door completely.
– Leave approximately 30inches of clearance in the back of the rack to allow for sufficient
airflow and ease in servicing.
Notice!
This equipment is intended for installation in Restricted Access Location or equivalent.
Notice!
This product is not suitable for use with visual display work place devices acccording to §2 of
the the German Ordinance for Work with Visual Display Units.
4.2.2 Rack precautions
!
Warning!
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special
precautions to ensure that the system remains stable. The following guidelines are provided
to ensure your safety:
– Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor
with the full weight of the rack resting on them.
– This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
– When mounting this unit in a partially filled rack, load the rack from the bottom to the top
with the heaviest component at the bottom of the rack.
– In single rack installations, attach stabilizers to the rack.
– If the rack is provided with stabilizing devices, install the stabilizers before mounting or
servicing the unit in the rack.
– In multiple rack installations, couple the racks together.
– Always make sure the rack is stable before extending a component from the rack.
– Extend only one component at a time - extending two or more simultaneously may cause
the rack to become unstable.

Bosch DIVAR IP 7000 Specifications

General

Microphone in	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Wi-Fi	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RAID levels	5, 6
Storage drive size	3.5 \
Storage drive capacity	120 GB
Storage drive interface	-
Installed storage drive type	SSD
Supported storage drive types	HDD & SSD
Total installed storage capacity	0.24 TB
Number of storage drives supported	10
Bus type	QPI
Stepping	C0
Scalability	1S
Processor code	SR14S
Processor cache	8 MB
Processor model	E3-1275V3
System bus rate	- GT/s
Processor series	Intel Xeon E3-1200 v3
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
On-board graphics card model	Intel® HD Graphics P4600
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Internal memory	8 GB
Memory clock speed	1666 MHz
Internal memory type	DDR3
Thermal solution specification	PCG 2013D
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Intel Identity Protection Technology version	1.00
Chassis type	Rack (2U)
Cooling type	Active
Product color	Black
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	740 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Type	Storage server
Optical drive type	DVD-RW
Operating system installed	Windows Storage Server 2012 R2
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Certification	CE, UL
Processor ARK ID	75464

Weight and Dimensions

Depth	648 mm
Width	437 mm
Height	89 mm
Weight	23600 g
