DIVAR IP 7000 (2U) Maintenance | en 49
Bosch Sicherheitssysteme GmbH Installation Manual 2016.07 | V2 | DOC
Notice!
Make sure that a monitor with DVI or DisplayPort connection, a keyboard and a mouse are
connected to the unit.
2. Press any key when prompted to start the recovery environment from DVD.
Note: Press any key only to start the recovery environment. Do not press any key during
the setup process.
3. Select one of the following:
– Initial Factory Setup (all data on the system will be lost)
(restores to factory default image and deletes all data on the HDDs)
or
– System Recovery (back to Factory Defaults)
(restores to factory default image; data on the HDDs will not be deleted)
Note:
Windows performs the setup. The screen displays the percentage of the process.
Notice!
Do not turn off the unit during the process. This will damage the Recovery media.
4. The unit starts from the Recovery media. If the setup is successfull. press Yes to restart
the system.
5. Windows performs the initial setup of the operating system. The unit restarts after
Windows has completed the setup.
6. After the restart of the unit, the factory default settings are installed and the Windows
configuration screen is displayed.
The factory default settings are:
– IP address: DHCP (Fallback: 192.168.0.200)
– Subnet mask: 255.255.255.0
– User: BVRAdmin
– Password: WSS4Bosch
10.15 Service and repair
The storage system is backed by a 3-year warranty. Issues will be handled according to Bosch
Service and Support guidelines.
The storage equipment is shipped with an original manufacturer Service and Support
agreement.
Bosch RMA Desk is the Single Point of Contact in case of failure but the Service and Support
obligations are fulfilled by the manufacturer or a partner.
In order to enable the manufacturer's Service and Support organization to fulfill the defined
Service Levels, the system must be re-registered. Otherwise, the defined service level cannot
be provided but only best effort.
A description what information is required and where to send is included in each shipment as
paper work. The description is also electronically available in the Bosch online product
catalogue.
Request for RMA
Please request an RMA for failed parts from one of the following Bosch RMA contacts.
– RMA Contact AMEC

Bosch DIVAR IP 7000 Specifications

General

Microphone in	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Wi-Fi	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RAID levels	5, 6
Storage drive size	3.5 \
Storage drive capacity	120 GB
Storage drive interface	-
Installed storage drive type	SSD
Supported storage drive types	HDD & SSD
Total installed storage capacity	0.24 TB
Number of storage drives supported	10
Bus type	QPI
Stepping	C0
Scalability	1S
Processor code	SR14S
Processor cache	8 MB
Processor model	E3-1275V3
System bus rate	- GT/s
Processor series	Intel Xeon E3-1200 v3
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
On-board graphics card model	Intel® HD Graphics P4600
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Internal memory	8 GB
Memory clock speed	1666 MHz
Internal memory type	DDR3
Thermal solution specification	PCG 2013D
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Intel Identity Protection Technology version	1.00
Chassis type	Rack (2U)
Cooling type	Active
Product color	Black
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	740 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Type	Storage server
Optical drive type	DVD-RW
Operating system installed	Windows Storage Server 2012 R2
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Certification	CE, UL
Processor ARK ID	75464

Weight and Dimensions

Depth	648 mm
Width	437 mm
Height	89 mm
Weight	23600 g
