Bosch DIVAR IP 7000 User Manual

24 en | System setup - first steps DIVAR IP 7000 (2U)
2016.07 | V2 | DOC Installation Manual Bosch Sicherheitssysteme GmbH
5 System setup - first steps
5.1 Introduction
The DIVAR IP 7000 systems are based on Windows Storage Server2012R2 operating system.
Windows Storage Server2012R2 systems provide a user interface for initial server
configuration, unified storage appliance management, simplified setup and storage
management, and support for Microsoft iSCSI Software Target.
It is specially tuned to provide optimal performance for network-attached storage. Windows
Storage Server2012R2 operating system provides significant enhancements in storage
management scenarios, as well as integration of storage appliance management components
and functionality.
This chapter is valid for DIVAR IP 7000 2U models that come with pre-installed hard drives.
The operating system of empty units loaded with third party hard drives will start normally,
but the added hard drives must be configured with the RAID utility prior to initial software
setup.
See also
– RAID setup, page 29
5.2 Setup instruction
All DIVARIP systems are preconfigured with default network, user and iSCSI settings.
– IP Address: automatically assigned by DHCP (fallback IP address: 192.168.0.200)
– Subnet mask: automatically assigned by DHCP (fallback subnet mask: 255.255.255.0)
Observe the following:
– DIVARIP needs to have an active network link during installation. Make sure that the
network switch you are connecting to is powered on.
– The default IP address must not be occupied by any other device in the network. Make
sure that the default IP addresses of existing DIVARIP systems in the network are
changed before adding another DIVARIP.
User with administrator rights:
– User: BVRAdmin
– Password: WSS4Bosch
5.3 Starting the application
DIVARIP system is ready to go out of the box. The application provides a simple to install and
intuitive to use solution for network surveillance systems.
To start the application:
1. Connect the unit and the cameras to the network.
2. Turn on the unit.
The Windows Storage Server2012R2 setup process starts.
3. Select the appropriate language for the installation, then click Next.
The Microsoft Software License Terms and the End User License Agreement (EULA) are
displayed.
4. Accept the license terms. Windows restarts.
5. After restart is finished, press CTR+ALT+DELETE. The Windows logon page is displayed.
6. Enter the default password WSS4Bosch.
7. After entering the password, a message is displayed that you must change the password
before logging on the first time. To confirm, click OK.
8. Change the password.

Bosch DIVAR IP 7000 Specifications

General

Microphone in	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Wi-Fi	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RAID levels	5, 6
Storage drive size	3.5 \
Storage drive capacity	120 GB
Storage drive interface	-
Installed storage drive type	SSD
Supported storage drive types	HDD & SSD
Total installed storage capacity	0.24 TB
Number of storage drives supported	10
Bus type	QPI
Stepping	C0
Scalability	1S
Processor code	SR14S
Processor cache	8 MB
Processor model	E3-1275V3
System bus rate	- GT/s
Processor series	Intel Xeon E3-1200 v3
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
On-board graphics card model	Intel® HD Graphics P4600
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Internal memory	8 GB
Memory clock speed	1666 MHz
Internal memory type	DDR3
Thermal solution specification	PCG 2013D
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Intel Identity Protection Technology version	1.00
Chassis type	Rack (2U)
Cooling type	Active
Product color	Black
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	740 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Type	Storage server
Optical drive type	DVD-RW
Operating system installed	Windows Storage Server 2012 R2
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Certification	CE, UL
Processor ARK ID	75464

Weight and Dimensions

Depth	648 mm
Width	437 mm
Height	89 mm
Weight	23600 g
