42/62 Bosch Rexroth AG Linear modules MKK/MKR-xxx-NN-3 | R320103169/2020-08
Guideway: Lubrication point 1 (a/b) BASA: Lubrication point 2, 4 (a/b)
Lubricant quantity (cm
3
) Lubricant quantity (cm
3
)
LSS / LPG / LCF LCO d
o
xP (mm) LSS / LPG / LCF LCO
MKK-040 0.30 0.60
12x2 0.17
0.1312x5 0.33
12x10 0.33
MKK-065 1.60 1.00
16x5 0.70
0.1316x10 0.85
16x16 1.20
MKK-080 2.80 1.70
20x5 1.00
0.1620x10 1.50
20x20 2.40
20x40 1.85 0.26
MKK-110 5.60 2.25
32x5 2.15
0.16
32x10 3.05
32x20 3.55
32x32 5.45
MKK-140 8.80 3.00
40x5 2.95
0.50
40x10 8.15
40x20 8.70
40x40 14.00
Guideway: Lubrication point 1, 3, 4 (a/b)
Lubrication quantity short carriage (cm
3
) Lubrication quantity long carriage (cm
3
)
LSS / LPG / LCF LCO LSS / LPG / LCF LCO
MKR-040 – – 0.30 0.60
MKR-065 – – 1.60 0.95
MKR-080 1.40 0.80 2.80 1.60
MKR-110 2.80 1.10 5.60 2.20
MKR-140 – – 8.80 3.00
MKR-145 – – 5.60
1)
2.20
1)
Table 11: Relubrication quantity MKK
Table 12: Relubrication quantities MKR
1)
per lubrication point
13.6 Relubrication
13.6.1 Relubrication quantity MKK / MKR
f Pay attention to the notes on lubrication ! 13
f Lubricants
! 13.3
f Lube fittings
! 13.4
f Note the operating conditions
! 17
f Determining the load ratio and technical data
! Product catalog
