ENGLISH
13.7 Lubrication MKx-165-NN-2
13.8 Lubrication MLR-080/110-NN-3
Linear modules with cam roller guide (MLR) are designed for oil lubrication� With initial greasing on delivery�
c Attention! Grease lubricants must not be used!
f Pay attention to the notes on lubrication
! 13
f Lube fittings
! 13.4
f Note the operating conditions
! 17
f Determining the load ratio and technical data
! Product catalog
f It is recommended to use oil with aviscosity of approx. 1,000 mm
2
/s (ISO VG 1000 ) at 40 °C.
R320103169/2020-08
| Linear modules MKK/MKR-xxx-NN-3 Bosch Rexroth AG 47/62
Guideway; lubrication point 4 (a/b)
Relubrication interval (km) Relubrication quantity
Short TT (cm
3
)
Relubrication quantity
Long TT (cm3)
MKR-165-NN-2 see relubrication interval MKR
–
8.0
Guideway; lubrication point 1 (a/b)
Relubrication interval (km) F
cgw
/C
y
≤ 0.50 Relubrication quantity (cm
3
)
MLR-080-NN-3 5,000 6.0
MLR-110-NN-3 5,000 12.5
Guideway; lubrication point 4 (a/b) Drive (BASA), lubrication point 4 (a/b)
d
o
xP (mm) Relubrication interval
(km)
Relubrication quantity
BASA (cm
3
)
MKK-165-NN-2
Lubrication of the ball rail system is
covered with the relubrication interval of
the drive (BASA).
40x5
see relubrication interval
MKK
5.0
40x10 9.0
40x20 10.0
40x40 16.0
Table 14: Lubricants MKx-165-NN-2
Table 15: Relubrication MKK
Table 16: Relubrication MKR
Table 17: Relubrication MLR
13.9 Repair
Repairs to the linear axis should only be performed by BoschRexroth.
Linear modules (MKx-165-NN-2) come with initial greasing with Dynalub 510 and are only designed for grease
lubrication using amanual grease gun�
f Pay attention to the notes on lubrication
! 13
f Lube fittings
! 13.4
f Note the operating conditions
! 17
f Determining the load ratio and technical data
! Product catalog
MKK/MKR Grease Consistency class
DIN51818
Recommended lubricants Alternative lubricants
-165 KP2K-20
(DIN 51825)
NLGI 2 Dynalub 510
Cartridge (400g) R341603700
Container (25kg)
R341603500
Elkalub GLS 135 / N2 (Chemie-Technik)
Tribol GR 100-2 PD (Castrol)
