17 / 38
ctrlX CORE
Housing dimensions
No. Name Connection type Connector type
(Integrated)
Mating connector and cable
(From outside)
1GBit/s Ethernet (configurable)
⑤ CF01 Slot for SD card
microSD card
– microSD card
⑥ XD10 24 V plug
U
L
2-pin (2-wire)
⑦ GB01 Battery case – –
10 Mounting, dismounting and electric
installation
10.1 Housing dimensions
Fig. 5: Front view
Mounting, dismounting and electric installation
