12.6 SD card
There is a slot for the micro SD card on the front of the control.
Use only SD cards available as accessories, see ⮫ Chapter 5.2 SD card on page 11. These SD
cards are formatted and tested for the control.
A correct functioning of other SD cards cannot be ensured.
12.7
USB interface
There is a USB interface (type C, USB 2.0) on the front of the control. The USB interface can be used to
connect USB memory media (only FAT16 and FAT32), scanners and similar USB devices.
The USB interface provides a voltage supply with 5 V DC and 0.5 A for external devices. The USB inter-
face is switched off up to the next voltage cycle when the current is exceeded.
The maximum cable length allowed is 3 m.
If there is an interrupted or unconnected ground at the 24 V power connector XD10, the con-
trol can be supplied externally via the USB interface.
12.8
Battery
A battery is included and working in the device upon delivery. Battery name: Lithium battery 3.0 V
CR1025 (32 mAH).
The battery is used to extend the buffer time of the real-time clock. A circuit monitors the battery state.
For notes on changing the battery, see ⮫ Chapter 14.2 Battery change on page 30.
A discharged battery causes an incorrect system time.
12.9
License information
This product contains software components that are licensed by the holder of the rights under GNU
General Public License (GPL), GNU Lesser General Public License (LGPL) or any other Open Source
Software license, which requires a provided source code
The source code of these software components is not delivered together with this product. You can
obtain the source code for these software components on a physical medium (CD or DVD) by submit-
ting a written request to our Open Source Office address listed below or by sending an email to
⮫ email>open.source@boschrexroth.de. When sending such a request, please name the relevant
product and its date of purchase.
Bosch Rexroth AG
Open Source Office
Zum Eisengießer 1
97816 Lohr a.Main
Germany
