30 VPV Vane Pump
VPV 25/32, Single pump, S.A.E. ‘B’ flange, RH rotation
,y
BOSCH
OUT
IN
IN
OUT
,y
{
{
|
,y
{
{
{
{
BOSCH
BOSCH
{
{
{
ø0.87
(ø22.2)
0.25
Square key
(6.35)
0.98
(25.0)
SCALE: 2X
5.75
(146.0)
0.56
(14.4)
S.A.E. "B"
mounting flange
ø4.00
(ø101.6)
6.63
(168.6)
4.58
(116.4)
1.57
(40.0)
Inlet port
#24 S.A.E.
Case drain port
#8 S.A.E.
5.17
(131.4)
7.06
(179.4)
3.53
(89.7)
7.05
(179.3)
3.35
(85.0)
Compensator adjusting
knob (cw rotation
increases pressure setting)
Centerline pump control
Rotation arrows
cast into body
#6 S.A.E.
Shock clipper port. Should
be plumbed to tank
to activate shock clipper
function (See page 97).
11.82
(300.2)
9.90
(251.5)
3.78
(96.0)
5.44
(138.2)
4.65
(118.1)
8.14
(206.8)
4.65
(118.0)
1.36
(34.5)
Pump centerline
Pump control
mounting
datum "T"
Optional volume
control (CW rotation
reduces flow)
1.61
(41.0)
0.31
(7.8)
0.56
(14.2)
Outlet port
#16 S.A.E.
4.46
(113.4)
5.26
(133.7)
max.
0.36
(9.25)
1.57
(40.0)
2.36
(59.7)
30° Involute Spline Data
Flat root side fit
Pitch . . . . . . . . . . .
Pressure angle . . .
Number of teeth. . .
Base dia. . . . . . . .
Form dia . . . . . . . .
Major dia. . . . . . . .
Class 5
16/32
30°
13
0.703645 in. ref..
0.749 in. ref.
0.875
+0.000
in. ref
-0.022
. . .
Optional combination capable pump with end cover
6.94
(176.3)
7.85
(199.3)
Remote control port
#4 SAE
Centerline
pump control
3.75
(95.5)
Optional 2-stage
compensator
Optional 2-stage
load compensator
2-stage compensator
adjusting knob
(CW rotation increases
pressure setting)
1.08
(27.5)
1.83
(46.6)
Centerline
pump control
Load sense port
#4 SAE
4.88
(123.9)
3.84
(97.7)
140 bar
4.16
(105.8)
210 bar
5.17
(131.4)
Inches (millimeters)
