6 VPV Vane Pump
Ordering Guide
Code Structure
The alpha-numeric ordering code system enables any particular type of pump to be specified.
Preferred type are also identified by a 10-digit part number for computerized ordering.
Item No Code
1 Code Digit
0513 Vane Pump, stand alone version single pump or combination
2 Direction of Rotation
R Clockwise, viewed from shaft end
3 Speed
12 maximum speed; e.g. 1150 rpm = 12
15 1450 rpm = 15
18 1750 rpm = 18
4 Drive Shaft
A Key to DlN 6885
C Key to SAE Standard
D Spline to SAE 744C
5 Bearing Arrangement / Mounting Flange
3 Standard bearing arrangement, mounting flange to SAE standards
7 Standard bearing arrangement, mounting flange to DIN ISO 3019/2
6 Principle of Operation
V Vane Type
7 Mode of Operation
P Pump
8 Type of Construction
V Variable displacement pump (open circuit)
K Fixed Displacement Pump (available in 1998)
9 Displacement
16 16 cc/rev = .98 cu in/rev
25 25 cc/rev = 1.53 cu in/rev
32 32 cc/rev = 1.95 cu in/rev
45 45 cc/rev = 2.75 cu in/rev
63 63 cc/rev = 3.84 cu in/rev
80 80 cc/rev = 4.88 cu in/rev
100 100 cc/rev = 6.10 cu in/rev
130 130 cc/rev = 7.93 cu in/rev
164 164 cc/rev = 10.00 cu in/rev
Item No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Pump 1 0513 R 18 C 3 V P V 32 S M 21 F Z B02
Pump 2*** V P V 32 S M 21 F Z B02
Pump 3 (Gear Pump) HY/Z F S11/ 14 R 254
*** When trailing pump is another VPV pump, it can be coded by selecting items 6 through 15 for the
alpha-numeric description. Consult factory for other models and descriptions of trailing pumps.
Price and Part Numbers
See VPV Pump Identification Guide, Publication # 9 535 233 782 for SAE, and 9 535 233 785 for metric
pumps.
Product Literature Disclaimer
Specifications and/or dimensions are subject to change without prior notice. Please consult factory.
