VPV Vane Pump 33
VPV 25/32, Single pump, S.A.E. ‘B’ flange, w/ solenoid 2-pressure compensator
BOSCH
OUT
IN
{
{
{
{
IN
OUT
{
{
{|
|
|
{
|
|
{
{|
|
,y
BOSCH
ø0.87
(ø22.2)
0.25
(6.35)
Square key
.098
(25.0)
8.39
(213.2)
4.58
(116.4)
1.57
(40.0)
Inlet port
#24 SAE
Case
drain port
#8 SAE
8.24
(209.2)
8.38
(212.9)
3.78
(96.0)
8.50
(216.1)
13.55
(344.2)
4.65
(118.1)
Pump control
mounting
datum "T"
1/2" conduit connector
w/ A.C. coil only
D.C. coil leads
w/o conduit connector
Optional volume
control (CW rotation
reduces flow)
0.36
(9.25)
0.36
(9.25)
0.31
(14.2)
Outlet port
#16 SAE
4.46
(113.3)
5.96
(151.4)
5.26
(133.7)
max.
1.57
(40.0)
5.17
(131.4)
2.05
(52.0)
Remote
control port
#4 SAE
3.78
(95.9)
5.75
(146.0)
0.56
(14.4)
S.A.E. "B"
mounting flange
ø4.00
(ø101.6)
5.17
(131.4)
7.06
(179.4)
3.53
(89.7)
7.05
(179.3)
3.79
(96.3)
Pump centerline
Rotation arrows
cast into body
4.65
(118.1)
2.03
(51.7)
3.63
(92.2)
4.59
(116.7)
(Optional)
DIN 43650 connector
w/ 1/2" NPT compression
fitting and sentinal light
(Optional)
Flying leads
Sentinel light
#6 SAE
Shock clipper drain
7/8-16 UN-2B thread
Manual
override
pushpin
Optional 2 pressure (vent)
solenoid operated compensator
3.50
(88.7)
3.80
(96.4)
(Optional)
5 pin connector
Inches (millimeters)
