44 VPV Vane Pump
VPV 25/32, Combination pump, S.A.E. ‘B’ flange, RH rotation
{
BOSCH
OUT
IN
{
{
|
IN
OUT
{
{
IN
OUT
,y
,y
z
|
BOSCH
0.25
Square key
(6.35)
{
4.13
(105.0)
3.41
(86.7)
4.13
(105.0)
3.41
(86.7)
0.4
(10.1)
0.4
(10.1)
Optional volume control
(CW rotation reduces flow)
Optional vertical supports
for combination pumps
when rotated 90°
ø0.47
thru, support holes
(ø12.0)
Outlet port,
#16 S.A.E.
Support (Lift) point
3/8" - 16UNC-2B X 22.0mm deep
5.26
(133.7)
max.
A
A
11.07
(281.2)
8.12
(206.3)
1.57
(40.0)
0.31
(7.8)
0.36
(9.25)
0.56
(14.2)
6.63
(168.6)
Outlet port
#16 S.A.E.
13.35
(339.2)
12.6
(326.2)
3.35
(85.0)
3.85
(98.0)
Ø4.00
(Ø101.6)
6.63
(168.6)
2.35
(59.7)
5.24
(133.3)
14.74
(374.5)
16.55
(420.5)
13.35
(339.2)
3.86
(98.0)
11.07
(281.1)
14.08
(357.7)
8.12
(206.3)
1.57
(40.0)
Remote
control
#4 S.A.E.
4.58
(116.5)
Inlet port,
#24 S.A.E
Case drain port,
#8 S.A.E
Inlet port,
#24 S.A.E
Case drain port,
#8 S.A.E
Support (Lift) point
3/8" = 16UNC-2B X 22.0mm deep
3.53
(89.7)
7.06
(179.4)
4.90
(124.3)
4.65
(118.0)
1.08
(27.5)
4.65
(118.0)
5.44
(138.2)
9.90
(251.5)
11.73
(297.9)
#6 S.A.E.
Shock clipper port. Should
be plumbed to tank
to activate shock clipper
function (See page 97).
Optional 2-stage
compensator (now
in modular design)
8.14
(206.8)
1.36
(34.5)
2-stage compensator
adjusting knob
(CW rotation
increases pressure setting)
Standard single stage compensator
Compensator
adjusting knob
(CW rotation
increases pressure setting)
VIEW A-A
0.56
(14.4)
5.75
(146.0)
ø0.87
(ø22.2)
0.98
(25.0)
S.A.E. 'B' 2-bolt
mounting flange
Inches (millimeters)
