58 VPV Vane Pump
VPV 45/63/80 to VPV 45/63/80, S.A.E. & Metric Combination
,

y
{
,y
z
IN
OUT
|
IN
OUT
T
T
,y
,yz
z
1.39
(35.23)
ø1.25
(ø31.74)
0.31
square key
(7.98)
9.31
(236.5)
5.91
(150.0)
5.96
(151.4)
13.03
(330.8)
5.91
(150.0)
5.96
(151.4)
13.03
(330.8)
7.13
(181.0)
0.69
(17.6)
DETAIL SAE-SAE
DETAIL METRIC-METRIC
SAE/METRIC SAE/METRIC
A
B
A
B
(SH.2 K-6)
(SH.2 D-6)
1.37
(34.9)
Ø1.26
(Ø32.0)
0.39 X 0.31
rectangular key
(10.0 X 8.0)
ø6.30
(ø160.0)
9.31
(236.5)
0.55
(14.0)
45° typ
METRIC 4-bolt
mounting flange
per ISO 3019/2
2.08
(52.8)
3.89
(98.9)
0.76
(19.2)
1.53
typ
(38.89)
Inlet port
std. SAE 2" pad
ø2.00
typ
(ø50.8)
"SAE" 1/2"-13UNC-2B TH'D
X
1.14
deep typ
"METRIC" M12 x 1.75-6H TH'D (29.0)
4 holes
3.06
typ
(77.78)
1.69
typ
(42.88)
0.84
typ
(21.44)
2.04
typ
(51.7)
Case drain port
"METRIC" 3/8-19 BSPP typ
"SAE" #8 S.A.E. typ
4.37
(111.0)
7.30
(185.5)
8.00
(203.1)
4.37
(111.0)
5.76
(146.2)
10.13
(257.2)
4.94
(125.4)
18.38
(466.8)
23.18
(588.8)
ø.69
thru support hole
(ø17.5)
5.22
(132.6)
Compensator adjusting knob
(CW rotation increases
pressure setting)
17.33
(440.3)
15.48
(393.1)
11.12
(282.4)
4.00
typ
(101.5)
Support (Lift) point
"SAE" 5/8"-11UNC-2B TH'D
X
1.30
deep
"METRIC" M16 X 2-6H TH'D (33.0)
2.08
(52.8)
S.A.E. "C" 2-bolt
mounting flange
per ISO 3019/1
Optional eye bolt
Compensator adjusting knob
(CW rotation increases
pressure setting)
1.91
(48.6)
Standard
2 stage compensator
Optional
2 stage compensator
Remote control port
7/16 – 20 UNF, 0.45/ (11.4) deep
6.61
(168.0)
7.44
(189.0)
Inches (millimeters)
