ELECTRICAL PART LIST
Input Module Assembly
Resistors
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
R52 332k, MF, 1/4W, 1% 1226.3323 183000 4
R53 332k, MF, 1/4W, 1% 1226.3323 183000 4
R54 332k, MF, 1/4W, 1% 1226.3323 183000 4
R55 332k, MF, 1/4W, 1% 1226.3323 183000 4
R56 120 Ohm, CF, 1/4W, 5% 1224.0121 182995 4
R57 10k, CF, 1/4W, 5% 1224.0103 182789 4
R58 10k, CF, 1/4W, 5% 1224.0103 182789 4
R59 120k, CF, 1/4W, 5% 1224.0124 182996 4
R60 332k, MF, 1/4W, 1% 1226.3323 183000 4
R61 10k, CF, 1/4W, 5% 1224.0103 182789 4
R62 332k, MF, 1/4W, 1% 1226.3323 183000 4
R63 330 Ohm, CF, 1/4W, 5% 1224.0331 182998 4
R64 10k, CF, 1/4W, 5% 1224.0103 182789 4
R65 30k, CF, 1/4W, 5% 1224.0303 182852 4
R66 51 Ohm, CF, 1/4W, 5% 1224.0510 4
R69 10k, CF, 1/4W, 5% 1224.0103 182789 4
R70 10k, CF, 1/4W, 5% 1224.0103 182789 4
R72 100k, CF, 1/4W, 5% 1224.0104 182790 4
R73 47k, CF, 1/4W, 5% 1224.0473 182928 4
R74 47k, CF, 1/4W, 5% 1224.0473 182928 4
R75 47k, CF, 1/4W, 5% 1224.0473 182928 4
R76 10k, CF, 1/4W, 5% 1224.0103 182789 4
R77 10k, CF, 1/4W, 5% 1224.0103 182789 4
R78 47k, CF, 1/4W, 5% 1224.0473 182928 4
R79 100k, CF, 1/4W, 5% 1224.0104 182790 4
R80 47k, CF, 1/4W, 5% 1224.0473 182928 4
R81 47k, CF, 1/4W, 5% 1224.0473 182928 4
R82 47k, CF, 1/4W, 5% 1224.0473 182928 4
R83 47k, CF, 1/4W, 5% 1224.0473 182928 4
R84 300 Ohm, CF, 1/4W, 5% 1224.0301 182997 4
R85 100 Ohm, CF, 1/4W, 5% 1224.0101 182994 4
R86 390 Ohm, CF, 1/4W, 5% 1224.0391 182951 4
R87 300 Ohm, CF, 1/4W, 5% 1224.0301 182997 4
R88 100 Ohm, CF, 1/4W, 5% 1224.0101 182994 4
R89 390 Ohm, CF, 1/4W, 5% 1224.0391 182951 4
