Switch PCB Assembly
Resistors
ELECTRICAL PART LIST
Capacitors
Diodes
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
- Connector, Terminal, PCMT, 1 Pos.
Mounting brackets for switch pc assy.
4227.0022 262159 Qty. 2
- Spacer, LED Standoff, .75 in.
LED standoff
5500.0002 262160 Qty. 1
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
R100 33k, MOF, 1W, 5% 1444.0333 262297 3
R101 33k, MOF, 1W, 5% 1444.0333 262297 3
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
C2 .01uF, Cer Disc, 250VAC, 10%,
UL/CSA
201-00035-00 3, 4
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
D2 LED, T-1, WHT DIFF LENS, AMBER 3600.0029 262094
D3 LED, RECT, 2x5MM, YELLOW
Standby LED
3600.0025 262158
D101 1N4004, 400V 3100.0017 182811 3
