Bose 2150 User Manual

44
Display PCB Assembly
ELECTRICAL PART LIST
Resistors
Capacitors
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
RT710 Pot, Rotary, 16mm, 5 KB, HZ, PCMT,
RA
4420.0015 262189
RT720 Pot, Rotary, 16mm, 5 KB, HZ, PCMT,
RA
4420.0015 262189
R700 150k, CF, 1/4W, 5% 1224.0154 182974 4
R701 12.1k, MF, 1/8W, 1% 1126.1212 4
R702 1.5k, MF, 1/8W, 1% 1126.1501 4
R703 12.1k, MF, 1/8W, 1% 1126.1212 4
R704 22.6k, MF, 1/8W, 1% 1126.2262 4
R705 12.1k, MF, 1/8W, 1% 1126.1212 4
R706 100k, MF, 1/8W, 1% 1126.1003 4
R707 7.5k, CF, 1/4W, 5% 1224.0752 182953 4
R708 7.5k, CF, 1/4W, 5% 1224.0752 182953 4
R709 150k, CF, 1/4W, 5% 1224.0154 182974 4
R710 12.1k, MF, 1/8W, 1% 1126.1212 4
R711 1.5k, MF, 1/8W, 1% 1126.1501 4
R712 12.1k, MF, 1/8W, 1% 1126.1212 4
R713 12.1k, MF, 1/8W, 1% 1126.1212 4
R714 100k, MF, 1/8W, 1% 1126.1003 4
R715 22.6k, MF, 1/8W, 1% 1126.2262 4
R716 7.5k, CF, 1/4W, 5% 1224.0752 182953 4
R717 7.5k, CF, 1/4W, 5% 1224.0752 182953 4
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
C700 1uF, AE, RDL, 50V, 20% 2930.0105 4
C701 1uF, AE, RDL, 50V, 20% 2930.0105 4
C703 10uF, AE, RDL, 35V, 20% 2930.0106 4
C704 10uF, AE, RDL, 35V, 20% 2930.0106 4
C705 10uF, AE, RDL, 35V, 20% 2930.0106 4
C706 10uF, AE, RDL, 35V, 20% 2930.0106 4
C707 10uF, AE, RDL, 35V, 20% 2930.0106 4
C708 10uF, AE, RDL, 35V, 20% 2930.0106 4
