ELECTRICAL PART LIST
Resistors
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
RT600 Thermistor, PTC, 2.2k 1200.0001 262126
R600 2.7k, CF, 1/8W, 5% 1124.0272 4
R601 10 Ohm, MF, 1/4W, 5% 1204.0100 182937 4
R602 100k, MF, 1/8W, 1% 1126.1003 4
R603 100k, MF, 1/8W, 1% 1126.1003 4
R604 1.00 MEG, MF, 1/8W, 1% 1126.1004 4
R605 100k, MF, 1/8W, 1% 1126.1003 4
R606 100k, MF, 1/8W, 1% 1126.1003 4
R607 1.00 MEG, MF, 1/8W, 1% 1126.1004 4
R608 10.0k, MF, 1/8W, 1% 1126.1002 4
R609 10.0k, MF, 1/8W, 1% 1126.1002 4
R612 10.0k, MF, 1/8W, 1% 1126.1002 4
R613 10.0k, MF, 1/8W, 1% 1126.1002 4
R614 15.4k, MF, 1/8W, 1% 1126.1542 4
R615 15.4k, MF, 1/8W, 1% 1126.1542 4
R616 100k, MF, 1/8W, 1% 1126.1003 4
R617 100k, MF, 1/8W, 1% 1126.1003 4
R618 0.01 Ohm, WW, 2W, 1% 1536.0107 262127
R619 0.01 Ohm, WW, 2W, 1% 1536.0107 262127
R620 0.01 Ohm, WW, 2W, 1% 1536.0107 262127
R621 0.01 Ohm, WW, 2W, 1% 1536.0107 262127
R622 100k, MF, 1/8W, 1% 1126.1003 4
R623 100k, MF, 1/8W, 1% 1126.1003 4
R624 4.7 Ohm, MF, Fuse, 1/4W, 5% 1204.0479 182808 3
R625 4.7 Ohm, MF, Fuse, 1/4W, 5% 1204.0479 182808 3
R626 4.7 Ohm, MF, Fuse, 1/4W, 5% 1204.0479 182808 3
R627 4.7 Ohm, MF, Fuse, 1/4W, 5% 1204.0479 182808 3
R628 1.00 MEG, MF, 1/8W, 1% 1126.1004 4
R629 1.00 MEG, MF, 1/8W, 1% 1126.1004 4
R634 29.4k, MF, 1/8W, 1% 1126.2942 4
R639 1k, MOF, 1W, 5% 1444.0102 262142
R640 1k, MOF, 1W, 5% 1444.0102 262142
R641 27 Ohm, MOF, 2W, 5% 1544.0270 262298
R642 27 Ohm, MOF, 2W, 5% 1544.0270 262298
R643 10 Ohm, MF, 1/4W, 5% 1204.0100 182937 4
R644 10 Ohm, MF, 1/4W, 5% 1204.0100 182937 4
R645 10.0k, MF, 1/8W, 1% 1126.1002 4
R646 .02 Ohm, WW, 5W, 5% 1734.0207 182935
R647 .02 Ohm, WW, 5W, 5% 1734.0207 182935
R648 29.4k, MF, 1/8W, 1% 1126.2942 4
R649 10 Ohm, MF, 1/4W, 5% 1204.0100 182937 4
Amplifier PCB Assembly (board part number 6000.0435)
