Bose 2150 User Manual

33
Interface PCB Assembly
ELECTRICAL PART LIST
Resistors
Capacitors
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
R801 10 Ohm, MF, Fuse, 1/4W, 5% 1204.0100 182937 3
R802 121 Ohm, MF, 1/8W, 1% 1126.1210 4
R803 121 Ohm, MF, 1/8W, 1% 1126.1210 4
R804 1.02k, MF, 1/8W, 1% 1126.1021 4
R805 1.02k, MF, 1/8W, 1% 1126.1021 4
R806 121 Ohm, MF, 1/8W, 1% 1126.1210 4
R807 121 Ohm, MF, 1/8W, 1% 1126.1210 4
R808 1.02k, MF, 1/8W, 1% 1126.1021 4
R809 1.02k, MF, 1/8W, 1% 1126.1021 4
R810 200 Ohm, MF, Fuse, 1/4W, 5% 1204.0201 182862 3
R811 100 Ohm, MF, Fuse, 1/4W, 5% 1204.0101 182806 3
R812 15k, CF, 1/4W, 5% 1224.0153 182848 4
R813 47k, CF, 1/8W, 5% 1124.0473 4
R814 10k, CF, 1/8W, 5% 1124.0103 4
R815 10k, CF, 1/8W, 5% 1124.0103 4
R816 51 Ohm, CF, 1/8W, 5% 1124.0510 4
R817 270 Ohm, CF, 1/8W, 5% 1124.0271 4
R818 68k, CF, 1/4W, 5% 1224.0683 4
R819 150k, CF, 1/8W, 5% 1124.0154 4
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
C801 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C802 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C803 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C804 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C805 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C806 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C807 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C808 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C809 100pF, Cer Disc, NPO, 100V, 5% 2174.0101 4
C810 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C811 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C812 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C813 330pF, Cer Disc, COG, 100V, 5% 2174.0331 182992 4
C814 100pF, Cer Disc, NPO, 100V, 5% 2174.0101 4
C815 100uF, AE, RDL, 25V, 5mm, 20% 2932.0107.01 4
C816 .1uF, MPE, 50V, 5% 2452.0104 4
C817 100uF, AE, RDL, 25V, 5mm, 20% 2932.0107.01 4
