ELECTRICAL PART LIST
Resistors
Digital Signal Processor (DSP) PCB Assembly
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
RN500 22k, RES NET x8, 16 Pin, DIP, 2% 1095.1223 262174
R1 Pot, Trim, 50k, 6mm, PC Mnt 4410.0017 262175
R2 Pot, Trim, 50k, 6mm, PC Mnt 4410.0017 262175
R4 4.99k, MF, 1/8W, 1% 1126.4991 4
R5 4.99k, MF, 1/8W, 1% 1126.4991 4
R6 374k, MF, 1/8W, 1% 1126.3743 4
R425 10.0k, MF, 1/8W, 1% 1126.1002 4
R426 4.23k, MF, 1/8W, 1% 1126.4321 4
R427 10.0k, MF, 1/8W, 1% 1126.1002 4
R428 4.23k, MF, 1/8W, 1% 1126.4321 4
R429 10k, CF, 1/8W, 5% 1124.0103 4
R430 10k, CF, 1/8W, 5% 1124.0103 4
R431 10.0k, MF, 1/8W, 1% 1126.1002 4
R432 10k, CF, 1/8W, 5% 1124.0103 4
R433 10k, CF, 1/8W, 5% 1124.0103 4
R434 36.5k, MF, 1/8W, 1% 1126.3652 4
R435 16.5k, MF, 1/8W, 1% 1126.1652 4
R436 10k, CF, 1/8W, 5% 1124.0103 4
R437 100k, CF, 1/8W, 5% 1124.0104 4
R438 1.5k, CF, 1/4W, 5% 1224.0152 4
R439 4.23k, MF, 1/8W, 1% 1126.4321 4
R440 1.5k, MF, 1/8W, 1% 1126.1501 4
R441 1.5k, CF, 1/4W, 5% 1224.0152 4
R442 100k, CF, 1/8W, 5% 1124.0104 4
R443 4.99k, MF, 1/8W, 1% 1126.4991 4
R444 36k, CF, 1/8W, 5% 1124.0363 4
R445 1.5k, CF, 1/4W, 5% 1224.0152 4
R446 100k, MF, 1/8W, 1% 1126.1003 4
R447 20.0k, MF, 1/8W, 1% 1126.2002 4
R448 4.99k, MF, 1/8W, 1% 1126.4991 4
R449 100k, MF, 1/8W, 1% 1126.1003 4
R450 20.0k, MF, 1/8W, 1% 1126.2002 4
R451 36k, CF, 1/8W, 5% 1124.0363 4
R452 18k, CF, 1/8W, 5% 1124.0183 4
R453 1.5k, CF, 1/4W, 5% 1224.0152 4
R454 47k, CF, 1/8W, 5% 1124.0473 4
R455 1k, CF, 1/8W, 5% 1124.0102 4
R456 10k, CF, 1/8W, 5% 1124.0103 4
R457 1.5k, CF, 1/4W, 5% 1224.0152 4
R458 10k, CF, 1/8W, 5% 1124.0103 4
R459 10k, CF, 1/8W, 5% 1124.0103 4
R460 1.5k, CF, 1/4W, 5% 1224.0152 4
R461 1k, CF, 1/8W, 5% 1124.0102 4
R462 100k, MF, 1/8W, 1% 1126.1003 4
R463 100k, MF, 1/8W, 1% 1126.1003 4
