Bose 2150 User Manual

45
Display PCB Assembly
ELECTRICAL PART LIST
Diodes
Miscellaneous
Integrated Circuits
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
D700 LED, RECT, 2x5mm, YELLOW 3600.0025 262158
D701 LED, RECT, 2x5mm, GREEN 3600.0024 262190
D702 LED, RECT, 2x5mm, GREEN 3600.0024 262190
D704 LED, RECT, 2x5mm, RED 3600.0023 262191
D705 LED, RECT, 2x5mm, RED 3600.0023 262191
D706 LED, RECT, 2x5mm, YELLOW 3600.0025 262158
D707 LED, RECT, 2x5mm, GREEN 3600.0024 262190
D708 LED, RECT, 2x5mm, GREEN 3600.0024 262190
D709 LED, RECT, 2x5mm, GREEN 3600.0024 262190
D710 LED, RECT, 2x5mm, GREEN 3600.0024 262190
D711 LED, RECT, 2x5mm, YELLOW 3600.0025 262158
D712 LED, RECT, 2x5mm, GREEN 3600.0024 262190
D713 LED, RECT, 2x5mm, YELLOW 3600.0025 262158
D714 LED, RECT, 2x5mm, RED 3600.0023 262191
D715 LED, RECT, 2x5mm, RED 3600.0023 262191
D716 LED, RECT, 2x5mm, GREEN 3600.0024 262190
D717 1N4148 3100.0004 182868
D718 1N4148 3100.0004 182868
D719 LED, RECT, 2x5mm, YELLOW 3600.0025 262158
D719 1N4148 3100.0004 182868
D720 1N4148 3100.0004 182868
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
U700 OP-AMP, DUAL, BA4560 3410.4560 262179
U701 OP-AMP, DUAL, BA4560 3410.4560 262179
U702 OP-AMP, DUAL, BA4560 3410.4560 262179
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
P700 Cable, IDC, SKT/CONN, 20
Conductor, 6 in
4148.0014 262153
